DATA
SHEET

Production: Current
Hire stock: Yes
New stock: Yes
Used stock: No
 Go Back one page
SPECIFICATIONS:
Technical:
Quantization 16-bit linear/channel, 3 beam laser
Oversampling rate 8 times
Frequency response 20Hz-20KHz
Channel separation 86dB
T.H.D. + NOISE 0.01%
S/N ratio (IHF-A) 94dB
Output level 2.0Vrms
Short access time
(Play next track) less than 1.7sec
Long access time
(Track 1 ->Track 20) less than 3sec
Start Time less than 0.3 sec
Pitch control range +/-12%
Pitch bend +/-16%
Digital Output type 2, form 1, S/PDIF
(Sony/Phillips Digital Interface Format)

GENERAL:
Environmental:
Operating Temperature 5-35 deg. C
Humidity 25 to 85% RH (non-condensing)
Storage Temperature -20 to 60 deg. C
Dimensions:
Main Unit: 482(W) x 88.8(H) x 264(D) mm (without feet)
19(W) x 3 1/2(H) x 10 3/8(D) inches (without feet)
Control Unit: 482(W) x 88.8(H) x 74(D) mm (without feet)
19(W) x 3 1/2(H) x 2 7/8(D) inches (without feet)
Weight: Player Unit: 5 Kgs., 11 lbs.
Control Unit: 2 Kgs., 4.4 lbs.
Power Supply: 115/230V AC, 50/60Hz
Power Consumption: 25W
Operating Temperature 5-35 deg. C
Humidity 25 to 85% RH (non-condensing)
Storage Temperature -20 to 60 deg. C
Dimensions:
Main Unit: 482(W) x 88.8(H) x 264(D) mm (without feet)
19(W) x 3 1/2(H) x 10 3/8(D) inches (without feet)
Control Unit: 482(W) x 88.8(H) x 74(D) mm (without feet)
19(W) x 3 1/2(H) x 2 7/8(D) inches (without feet)
Weight: Player Unit: 5 Kgs., 11 lbs.
Control Unit: 2 Kgs., 4.4 lbs.
Power Supply: 115/230V AC, 50/60Hz
Power Consumption: 25W

Numark Professional DJ / Broadcast twin CD player

Numark CDN22 twin CD player

KEY FEATURES:
Large coloured Play and Cue Buttons
Large clear backlit LCD display
Relay - Fader Start
Digital Output
Accurate Frame search
Auto dead-space elimination
+10 tracks skip search
20 tracks program play
12% Pitch adjust with display
True Continuous Play
Time Bar Display
CDR and 8cm single CD compatible
Loop Button

  Price to rent

replacement neoprene rubber drive belt for door eject mechanism

How to replace a drive belt

Replacement drawer drive belt (BELT695) available for 7.58 + 0.75 (UK p&p) + VAT @ 20% = 10.00 for one or 19.09 for a pair.
