Specifications
Line Input: 1/4" jack
Microphone input: XLR3
Outputs: L+R 2 x 1/4" jacks
Input Level: switchable -10dBm 1MΩ or +4dBm
Frequency Response: unknown (effect)
Remote control socket for external FS300 footswitch
Power: 9VAC
Dimensions (mm): 286 w x 180 d x 46 h
Weight: 1270g excluding PSU.

Free Digitech VHM5 user manual

Note: We have replacement 230V UK power supplies available for this unit.

YouTube demonstration of the Vocaliser (straight to the demo? start video at 1m15)

FEATURES:
The VHM5 is capable of many voices and can generate choirs from a lead vocal. Practical tool for use on stage or in the studio, with an extraordinary quality. Line input, microphone XLR. Control via keyboard or interface / MIDI keyboard in. Mixing dry / effect.  Effect and harmonic modes pre-selections: 256 users presets and presets.

• Diatonic chordal harmonies, and 5 parts natural harmonies
• Vocoder
• Auto-tune / pitch correct
• Chorus, portamento, dj voice
• Vibrato-programmable
• Optional FS300 footswitch remote control
• Compact body with an octave keyboard
